When we first wrote about P-Tier in 2022, our post covered two machines: the 350 and 380 mid-size excavators. Today John Deere sells 23 P-Tier excavators, from the 3,920 lb 17 P-Tier to the 188,716 lb 870 P-Tier. This page lists every one with Deere's headline numbers and a link to its CL Boyd product page, then covers the 350 and 380 in more detail.
The P-Tier lineup at a glance
- Compact excavators: six models, the 17 through the 60 P-Tier, from 18.52 hp to 53 hp.
- Mid-size excavators: twelve models from the 75 to the 380 P-Tier, 67.6 hp to 271 hp, plus the 223 hp 300 P-Tier.
- Large excavators: the 510, 670 and 870 P-Tier, from 367 hp to 512 hp.
Every number below is the figure Deere lists on that model's product page. Weight and digging depth change with arm length, counterweight, tracks and cab, so where Deere gives a range we show the range.
Compact P-Tier excavators
| Model | Net power | Operating weight | Max digging depth |
|---|---|---|---|
| John Deere 17 P-Tier | 18.52 hp | 3,920 lb | 7 ft 10 in |
| John Deere 26 P-Tier | 18.52 hp | 5,795 lb | 8 ft 7 in |
| John Deere 30 P-Tier | 23 hp | 7,220 lb | 9 ft 2 in |
| John Deere 35 P-Tier | 23.3 hp | 8,135 lb | 10 ft 0 in |
| John Deere 50 P-Tier | 35.9 hp | 10,847 lb | 11 ft 7 in |
| John Deere 60 P-Tier | 53 hp | 13,620 lb | 12 ft 4 in |
The 26 P-Tier weight is Deere's figure with a cab.
For the two smallest machines, our John Deere 17 P-Tier comparison guide lines it up against the Kubota U17-5, Cat 301.7 CR and Hitachi ZX17U-5N, and our John Deere 26 P-Tier comparison guide does the same against the Bobcat E26, Kubota U27-4, Cat 302.7 CR and Yanmar ViO25-6B.
We have compared the 35 P-Tier head to head with the Cat 303 CR, Bobcat E35 and Kubota U35-4, and our John Deere 35 P-Tier comparison guide brings those reviews together.
Mid-size P-Tier excavators
| Model | Net power | Operating weight | Max digging depth |
|---|---|---|---|
| John Deere 75 P-Tier | 67.6 hp | 18,559 to 19,326 lb | 15 ft 3 in |
| John Deere 85 P-Tier | 67.6 hp | 19,238 to 20,296 lb | 14 ft 10 in |
| John Deere 130 P-Tier | 98 hp | 29,531 lb | 19 ft 9 in |
| John Deere 135 P-Tier | 101 hp | 31,526 to 33,951 lb | 20 ft 0 in |
| John Deere 160 P-Tier | 122 hp | 39,526 lb | 21 ft 4 in |
| John Deere 210 P-Tier | 157 hp | 49,380 to 51,370 lb | 21 ft 10 in |
| John Deere 230 P-Tier | 170 hp | 52,800 to 55,560 lb | 21 ft 10 in |
| John Deere 245 P-Tier | 159 hp | 56,879 lb | 21 ft 8 in |
| John Deere 250 P-Tier | 188 hp | 60,600 lb | 25 ft 0 in |
| John Deere 260 P-Tier | 202 hp | 56,550 to 60,410 lb | 23 ft 7 in to 25 ft 7 in |
| John Deere 300 P-Tier | 223 hp | 68,674 lb | 25 ft 10 in |
| John Deere 345 P-Tier | 249 hp | 78,705 lb | 24 ft 10 in |
| John Deere 350 P-Tier | 271 hp | 80,985 lb | 26 ft 10 in |
| John Deere 380 P-Tier | 271 hp | 85,462 lb | 26 ft 10 in |
Deere's lineup page lists the 300 P-Tier as an excavator without a size class; we show it here by weight. We covered the 210, 230 and 260 P-Tier when Deere introduced them: Meet the New John Deere 210, 230 and 260 P-Tier Excavators.
Large P-Tier excavators
| Model | Net power | Operating weight | Max digging depth |
|---|---|---|---|
| John Deere 510 P-Tier | 367 hp | 111,885 lb | 25 ft 6 in to 27 ft 2 in |
| John Deere 670 P-Tier | 463 hp | 154,103 lb | 23 ft 4 in to 30 ft 0 in |
| John Deere 870 P-Tier | 512 hp | 188,716 lb | 23 ft 5 in to 36 ft 7 in |
Digging depth on the large excavators is a range because Deere offers several boom and arm combinations on each.
John Deere 350 and 380 P-Tier
Deere lists up to 7% better fuel economy than the 350G LC and 380G LC they are compared against, along with improved front-joint durability and a redesigned hood that makes service and cooler access easier. A control pattern-change valve comes standard, so operators can switch patterns with the flip of a lever.
For grade control, Deere offers 2D or 3D Excavator Grade Guidance, or fully integrated SmartGrade for 3D control with overdig protection and real-time distance to target in the cab. All of these grade options are factory ready.
The two machines share a 271 hp engine and the same listed reach, depth and dump height. The 380 is the heavier machine.
| Spec | John Deere 350 P-Tier | John Deere 380 P-Tier |
|---|---|---|
| Operating weight | 80,985 lb | 85,462 lb |
| Net power (ISO 9249) | 271 hp | 271 hp |
| Max digging depth, 10 ft 6 in arm | 24 ft 3 in | 24 ft 3 in |
| Max digging depth, 13 ft 1 in arm | 26 ft 10 in | 26 ft 10 in |
| Max reach, 10 ft 6 in arm | 36 ft 5 in | 36 ft 5 in |
| Max reach, 13 ft 1 in arm | 38 ft 11 in | 38 ft 11 in |
| Max dump height, 10 ft 6 in arm | 23 ft 9 in | 23 ft 9 in |
| Max dump height, 13 ft 1 in arm | 25 ft 0 in | 25 ft 0 in |
Figures from the John Deere 350 P-Tier brochure and 380 P-Tier brochure.
Frequently asked questions
Deere lists 23 P-Tier excavators: six compact, twelve mid-size, three large, and the 300 P-Tier, which Deere lists without a size class.
The 17 P-Tier, at 3,920 lb and 18.52 hp.
The 870 P-Tier, at 188,716 lb and 512 hp.
Weight. The 380 weighs 85,462 lb and the 350 weighs 80,985 lb. Deere lists the same 271 hp engine and the same digging depth, reach and dump height for both.
26 ft 10 in with the 13 ft 1 in arm, and 24 ft 3 in with the 10 ft 6 in arm.
Yes. Deere offers fully integrated SmartGrade for 3D control, as well as 2D and 3D grade guidance, and all of them are factory ready.
Oklahoma owners get support from CL Boyd in Oklahoma City, Lawton and Ardmore.
