Front left view of Pallet Fork Attachment on 333G Compact Track Loader

John Deere 45IN. HD

Compact Equipment Attachment

The P45 Heavy-Duty Pallet Fork offers exceptional durability and versatility, enabling seamless handling of large loads with precision and reliability, making it an essential attachment for efficient operation in demanding environments.

Product Features:

  • Improved Visibility
  • Increased Capacity
  • Durable, Heavy-Duty Frame
  • Ease of Access with Skid-Resistant Steps
View Product Brochure

Specifications

Frame Width 1410 mm
Frame Width 55 in.
Frame Height 990 mm
Frame Height 39 in.
Overall Length with Frame and Two Minimum Length Tines 1310 mm
Overall Length with Frame and Two Minimum Length Tines 52 in.
Overall Length with Frame and Two Maximum Length Tines 1470 mm
Overall Length with Frame and Two Maximum Length Tines 58 in.

Fork Suspension Class ITA Class II
Minimum Fork Tine Length 1065 mm
Minimum Fork Tine Length 42 in.
Maximum Fork Tine Length 1220 mm
Maximum Fork Tine Length 48 in.
Fork Tine Pair Load Rating 1814/2495/2812 kg
Fork Tine Pair Load Rating 4000/5500/6200 lb.
Fork Thickness 36/40/45 mm
Fork Thickness 1.4/1.6/1.8 in.
Fork Spacing 102 mm
Fork Spacing 4 in.

Overall Weight with Frame and Two Minimum Length Tines 181/187 kg
Overall Weight with Frame and Two Minimum Length Tines 397/412 lb.
Overall Weight with Frame and Two Maximum Length Tines 189/198 kg
Overall Weight with Frame and Two Maximum Length Tines 416/435 lb.

Compact Track Loaders 317G, 325G, 331G, 333G, 331 P-Tier, 333 P-Tier, 335 P-Tier
Skid Steer Loaders 316GR, 318G, 320G, 324G, 330G, 332G, 330 P-Tier, 334 P-Tier
